316L stainless steel casing
Utilizing German-imported chips ensures stable performance
Edible silicone oil can be used for oil injection and is applicable in the food,medical, pharmaceutical, and related industries.
Lumen-free flat design for easy disassembly and cleaning
performance parameters
Test conditions: temperature (20~30℃), power supply (1.5mA)
parameter | |
power supply | 1.5mA constant current power supply |
range | -100kPa...0~10kPa...6MPa |
nonlinear | 0.25%FS |
zero output | ±2mV |
full output | ≥40mV(10kPa);≥60mV(Other ranges) |
zero temperature drift | ＜1%FS |
sensitivity temperature drift | ＜1%FS |
insulation resistance | ≥200MΩ（250VDC） |
compensation temperature | -10℃~70℃ |
Operating Temperature | -20℃~120℃ |
long-term stability | ≤0.2%FS/Year |
