316L stainless steel casing
Utilizing German-imported chips ensures stable performance
Edible silicone oil can be used for oil injection and is applicable in the food,medical, pharmaceutical, and related industries.
Lumen-free flat design for easy disassembly and cleaning
performance parameters
Test conditions: temperature (20~30°C), power supply (1.5mA)
| parameter | |
| power supply | 1.5mA constant current power supply |
| range | -100kPa...0~10kPa...6MPa |
| nonlinear | 0.25%FS |
| zero output | ±2mV |
| full output | >40mV(10kPa);≥60mV(other ranges) |
| zero temperature drift | <1%FS |
| sensitivity temperature drift | < 1%FS |
| insulation resistance | ≥200M0 (250VDC) |
| compensation temperature | 10°C~70°C |
| Operating Temperature | -20°C~120°C |
| long-term stability | ≤0.2%FS/year |
